HeroPremium Series
Heating & Cooling Heat Pump
PHNIX HeroPremium Series is an R32 full inverter EVI air-to-water heat pump created for year-round residential heating, cooling and domestic hot water. Combining dependable cold-climate performance, quiet operation and a distinctive screw-free ASA design, it brings comfort, efficiency and style together in one system. Flexible connected control and OEM/ODM options make it a differentiated choice for brands, importers and distributors expanding their residential heat pump range in North America.
Product Details
-
R32 RefrigerantA lower-GWP alternative to R410A for more climate-conscious residential HVAC solutions. -
Heating, Cooling & DHWOne system for year-round indoor comfort and domestic hot water. -
Year-round PerformanceReliable operation from -13°F to 109°F (-25°C to 43°C). -
Outlet Water Temp. Up to 140°FHigh-temperature water for space heating and domestic hot water applications. -
Full DC Inverter EVIVariable-speed operation maintains stable performance as outdoor conditions and heating demand change. -
High-Efficiency PerformanceA+++ energy classification under European ErP testing demonstrates strong seasonal efficiency. -
Whisper-Quiet OperationSound pressure as low as 39 dB(A) at 1 m under minimum-flow operation. -
Smart Touch ControlA clear color display makes temperature settings, scheduling and system monitoring easier. -
Connected System ManagementOptional remote connectivity supports easier monitoring and service management.
-
Full DC Inverter EVI TechnologyHeroPremium continuously adjusts compressor output to match real-time heating or cooling demand. EVI technology strengthens low-temperature performance, allowing the system to maintain dependable home heating at temperatures as low as -13°F (-25°C). Under partial-load conditions, the unit reduces output to maintain steadier temperatures with less unnecessary energy use. -
Quiet Performance for Residential LivingA dedicated soundproof internal structure reduces sound pressure to as low as 38 dB(A) at 1 m under minimum-flow operation. Quieter performance gives homeowners greater everyday comfort while offering installers more flexibility when positioning the outdoor unit near residential living areas. -
Screw-Free ASA ExteriorHeroPremium combines a distinctive wave profile with a screw-free ASA casing for a cleaner, more integrated appearance. The corrosion-resistant material helps protect the unit against changing outdoor conditions, while its modern design gives brands and OEM/ODM partners a visually differentiated product for higher-value residential HVAC ranges.
Product parameters
| Model | PASRW020-BP-PS-B | PASRW040-BP-PS-B | PASRW040S-BP-PS-B | PASRW060-BP-PS-B | PASRW060S-BP-PS-B | |
| Power Supply | / | 220~240V~/50Hz | 220~240V~/50Hz | 380~415V/3N~/50Hz | 220~240V~/50Hz | 380~415V/3N~/50Hz |
| Heating Condition - Ambient Temp. (DB/WB): 7/6°C, Water Temp. (In/Out): 30/35°C | ||||||
| Heating Capacity Range | kW | 2.30~8.20 | 3.80~12.50 | 3.80~12.50 | 7.00~23.00 | 7.00~23.00 |
| Heating Power Input Range | kW | 0.50~1.84 | 0.80~2.95 | 0.80~2.95 | 1.47~5.90 | 1.47~5.90 |
| Heating Current Input Range | A | 2.17~8.00 | 3.48~12.80 | 1.33~4.92 | 6.50~25.90 | 2.60~10.42 |
| Cooling Condition - Ambient Temp. (DB/WB): 35/24°C, Water Temp. (In/Out): 12/7°C | ||||||
| Cooling Capacity Range | kW | 1.56~6.00 | 2.20~10.00 | 2.20~10.00 | 4.35~15.00 | 5.30~15.00 |
| Cooling Power Input Range | kW | 0.63~2.36 | 1.10~3.80 | 1.10~3.80 | 1.65~6.59 | 2.03~6.59 |
| Cooling Current Input Range | A | 2.74~10.30 | 4.78~8.26 | 1.84~6.36 | 7.58~30.00 | 3.59~11.64 |
| Hot Water Condition - Ambient Temp. (DB/WB): 20/15°C, Water Temp. (In/Out): 15/55°C | ||||||
| Hot Water Capacity Range | kW | 3.00~9.50 | 4.15~16.00 | 4.15~16.00 | 8.80~26.20 | 8.80~26.20 |
| Hot Water Power Input Range | kW | 0.62~2.30 | 0.90~3.85 | 0.90~3.85 | 2.10~6.29 | 2.10~6.29 |
| Hot Water Current Input Range | A | 2.70~10.00 | 3.91~17.2 | 1.50~6.43 | 9.22~27.60 | 3.71~11.11 |
| Max. Power Input | kW | 2.9 | 4.95 | 4.95 | 6.6 | 8.3 |
| Max. Current Input | A | 13 | 21.4 | 8 | 30 | 15 |
| Water Flow | m³/h | 1 | 1.7 | 1.7 | 2.9 | 2.9 |
| Refrigerant / Proper Input | kg | R32 / 1.1kg | R32 / 1.8kg | R32 / 1.8kg | R32 / 2.0kg | R32 / 2.0kg |
| CO₂ Equivalent | Ton | 0.74 | 1.22 | 1.22 | 1.35 | 1.35 |
| Sound Pressure (1m) | dB(A) | 41 | 43 | 43 | 44 | 45 |
| Sound Power Level EN 12102 | dB(A) | 55 | 58 | 60 | 61 | 61 |
| Operating Ambient Temperature | °C | -25~43 | ||||
| Max. Water Temperature | °C | 60 | ||||
| Fan Quantity | / | 1 | 1 | 1 | 2 | 2 |
| Fan Motor Type | / | DC | ||||
| Water Connection | inch | 1 | ||||
| Water Pressure Drop (max) | kPa | 40 | 45 | 45 | 69 | 69 |
| Circulation Pump Water Head | m | 7.5 | 7.5 | 7.5 | 12.5 | 12.5 |
| ErP Level(35°C) | / | A+++ | ||||
| Cabinet Type | / | Galvanized sheet+ASA | ||||
| Unit Dimension(L/W/H) | mm | 1167×407×795 | 1287×458×928 | 1287×458×928 | 1250×540×1330 | 1250×540×1330 |
| Shipping Dimensions(L/W/H) | mm | 1300×485×940 | 1420×540×1080 | 1420×540×1080 | 1380×570×1480 | 1380×570×1480 |
